Mercedes Benz SLK Luggage Rack – All models

Mercedes Benz SLK Luggage Rack

Revo-Rack Black C$559.95

Revo-Rack PA C$659.95

red mercedes slk with a black luggage rack fitted carrying large black holdall next to a hedge

No metal clamps tried and tested by customers since 2016 certified to carry 20kg

Revo-Rack is a unique design of Mercedes Benz SLK Luggage Rack that eliminates the risk of paint damage, caused by steel clamps or straps on the fragile trunk lid edges. Revo-Rack can be fitted in under a minute.

We have been manufacturing the Revo-Rack since 2016 with the choice of two finishes black or PA (polished anodised) which creates a chrome like shine. We only sell direct over the web.

We designed Revo-Rack in 2015. The issue with fitting a conventional metal clamp based luggage rack to a modern convertible is the small panel gap - there is no room for a metal clamp.

Revo-Rack attaches to your Mercedes using vacuum cup technology, these are not suction cups. Suction is what creates vacuum. Vacuum is the total absence of air whereas suction is the process done to achieve a vacuum. The grey buttons on the side of the cups pump out the air creating a huge, securing force.

close up of a revo-rack luggage rack on an XXX

The grey buttons pump the air out. These are not suction cups

In 2015 Revo-Rack was independently certified by TUV Italy part of the global TUV testing and certification business. It went through speed, braking and force tests, to ISO 11154:2006 Revo-Rack passed all these tests and is certified to carry 20kg/45lbs. Since 2016 we have sold over 10,000 Revo-Racks and never had a failure.

Please see what our customers think of the Revo-Rack

Why a Revo-Rack Mercedes Benz SLK Luggage Rack ?

  • Shipped to Canada in 3-10 days with DHL
  • No clamps
  • No bolts
  • No paint damage
  • No fiddly brackets or clamps to do up
  • In manufacture since 2016 tried tested and enjoyed by thousand's globally
  • Conceived, designed and engineered for the SLK's small panel gaps and curvy trunk lid
  • All Mercedes SLK's have a panel gap thats too thin for a traditional clamp on the trunk edge 3mm ish.
  • Revo-Racks load carrying capacity has been rated at 20kg / 45Ibs
  • Not immediately obvious how to release the rack from the trunk lid - Impossible to pull off, therefore theft is difficult.
  • If you do stop for a prolonged period and are concerned about your luggage we suggest you remove the rack and luggage and place it inside your car, a 60 second task.
  • The Revo-Rack is supplied with two luggage straps and a cotton storage bag

The Rack Frame :

This Mercedes Benz SLK luggage rack is manufactured from 25mm/ 1" 6063-T5 tubing this is an aluminium and magnesium alloy ( it will never rust )  As a result the rack frame weighs only 1.672kg / 3.6lb perfect for todays aluminium and composite boot/trunk lids. The cross bars are machine welded in place to ensure consistency, the rack is powder coated black or hand polished & anodised. The rack measures 900x420mm  /  36"x17"

The Supports :

The rack is secured to your SLK's trunk lid using three 115mm vacuum cups,  rated by the manufacturer as capable of holding an 18kg/40lb load each.

Vacuum cups employ the force of atmospheric pressure to grip a surface: When a vacuum exists between the cup and the surface on which it is attached, the weight of Earth's atmosphere holds the cup in place with incredible force. Unlike suction cups that produce a vacuum as they pull away from the surface, Revo-Racks vacuum cups use a hand-actuated pump to efficiently remove air from between the rubber pad and the attaching surface thus creating a much more reliable hold. Because the full face of the pad is brought into contact with the surface, distortion is reduced, allowing the cup to be used with very little risk of damage.

The Revo-Racks vacuum cup's pump feature a plunger with a red line, which serves as a vacuum indicator. Introduced in the1960's, this safety device is still recognized as one of the most reliable warning systems available. A few strokes of the plunger evacuate the vacuum pad, causing it to seal securely to the attaching surface. When the cup is attached completely, the plunger stops moving and the red line is hidden within the pump. A visible red line indicates if air has leaked back into the pad, making vacuum insufficient to use the cup. However, if the red line becomes visible while the cup is in use, a check valve allows the user to re pump the cup without losing the remaining vacuum.

Lifting on the release tab near the edge of the pad allows air to refill the evacuated space, so that the vacuum cup detaches completely. The racks sits 7.5cm / 3" off the trunk lid



mercedes slk luggage rack close

Vacuum cup pumped and secured to paintwork

mercedes slk luggage rack

Soft rubber cannot chip mark or scratch paintwork

silver mercedes slk r170 on a drive with a black luggage rack fitted

Revo-Rack Black fits all SLK models

dark blue mercedes slk r171 350 with a stainless steel luggage rack fitted

Shipped to Canada in 3-10 days with DHL tracked all the way

mercedes benz slk stainless steel luggage rack

Revo-Rack PA is hand polished for a deep shine

mercedes benz slk stainless luggage carrier

Does not interfere with the sat nav fin on some models

revo rack mercedes benz slk r171 MK2 luggage rack

No fiddly clamps or brackets that damage paint

mercedes benz slk r171 2004 2005 2006 2007 2008 2009 2010 2011 luggage rack

Lightweight aluminium frame on R171 SLK (04-11) : old cups with blue buttons now grey

Optional anti theft strap secures the Revo-Rack if you leave the car unattended.

burgundy mercedes slk with a luggage rack attached carrying a set of two ski's

Revo-Rack can also be used to carry ski's with our ski rack attachment.

luggage rack on slk damaging paint

Metal on paint only ever ends one way

No 3M stickers to compensate for poor design

One use stickers to protect paint an admission of poor design we think





Silver mercedes slk r172 with. luggage rack fitted carrying a wheelchair overlooking the sea next to a green motorbike

Received via Instagram

On holiday with Ann & my mum 3 people 1 motorbike 1 car ( and a wheelchair ), easy to fit and works like a treat impressed with the Revo-Rack from boot-bag Group

Pennydave

15.9.22

dark blue mercedes benz slk 350 R171 with a revo-rack luggage rack fitted in. a pakring space next to grass

Dear Boot-bag team ,

I enjoyed the Revo Rack a lot and it functioned well for around 5000 km this season.

Kind regards

Allen

Netherlands

27.9.21

black mercedes slk r171 wth a revo-rack luggage rack fitted carrying two snowboards

hi Liza

We have used the Revo-Rack and its great and easy to use...its the best solution ever to carry extra stuff on a sports car. The attachment by the rack is very strong. Couldn't believe it until I tired it myself.

Photo attached with the trip.

Pat

NSW

Australia

10.8.17

Revo Rack Mercedes Benz SLK Luggage Rack ; Fitted in 90 seconds

Revo Rack SLK Luggage Rack ; Secure, Stable, Safe
